SPECIFICATIONS

Brand Name: kebidumei

Choice: yes

High-concerned chemical: None

Model Number: 7 Color Backlit Wireless Air Mouse Keyboard

Origin: Mainland China

Package: Yes

Support APP: No

Use: TV,Universal

Wireless Communication: Bluetooth

2.4G MODE

For initial use , plug a USB receiver into the USB port of device and wait for 20-60 seconds to install driver of USB receiver . Move the mouse the mouse cursor can move on the screen means that pairing is successful

if it is unsuccessful , press and hold [ OK and [ BACK ] buttons , LED light begin to flash . Pairing is successful when LED light stop flashing

BT 5.0 MODE

1 . Before using this device , first you must turn on the BT function of the lain device

2 . Then long press " OK + Return keys , when the LED turns to flash quickly, the product enters the pre pairing

3 , Click add search new devices on the main device to find this air remotes name ( Example : BT-REMOTE ) . Click the name can to connecting

4 . After the product is successfully connected , the direction of the mouse pointer can be controlled by waving in the air

5 .If the connection is not successful , please perform the operation steps of item 2-4 again

6 . Reconnect efficiency description : The normal reconnect time of this product is 3-5 seconds after it is normally paired with the main equipment

7 . This product can only remember the pairing information of one main device , when the product is connected to a new device , the connection of historical devices is not supported after

8 . in this case . you need to delete the historical connection information of this peripheral can be successfully matched for new search

CPI ADJUSTMENT

CPI ( Count Per Inch ) . Speed of the Mouse Cursor

Adjustment ( 3 Levels ) , 1 , 2 , 3 Level . The higher the level , the faster the speed . The default speed is set at level 2

1 . Speed Increase

Press OK button + Volume + ] button for about 3seconds , the work indicator flashes quickly and then goes off , release the button , CPI on the basis of the original increase 1 level

2 . Speed Decrease

Press [ OK ] + Volume - for about 3 seconds , the work indicator flashes quickly and then goes off ,release the button , and CPI is reduced by 1 level on the basis of the original
